ARGB Water Flow Dynamic Piping

· 14 Exchange Runner Cooling Row

· 20mm Cooling Fins

· 2700 RPM ARGB Fan (PWM)

· Thermal Grease, Conductivity >13.4W/M-K

· 2500RPM±10% Silent Water Pump

· EPDM+IIR High Density Water Pipe

· Precise Leak-Proof Structure

Model

MT240 / MT360

Scope of Application

Intel（LGA 775/115x/1366/2011/2066）

&

AMD（AM4/FM2/FM1/AM3/AM2/FM3）

Radiator

Dimensions

277*120*27 mm（MT240） / 397*120*27 mm （MT360）

Material

Aluminum

Tube

Dimensions

390mm*20mm

Pump

Dimensions

73*86.5*51mm

Speed

2500 RPM±10%

Noise

≤30dB（A）

Connector

3Pin+ARGB

Rated Voltage

12V DC

Rated Current

≤0.30A

Power Consumption≤3.6W

CPU POWER MAX

200 W(MT240) / 300 W(MT360)

Fan

QTY

2 pcs / 3 pcs

Dimensions

120*120*25 mm

Speed

800-2500 RPM±10%

Airflow

95.34 CFM

Air Pressure

3.33 mmAq

Noise

≤38.09dB(A)

Connector

4 Pin+ARGB

Bearing Type

Hydro Bearing

Rated Voltage12V DC

Rated Current0.46 A±10%

Power Consumption5.6 W±10%

LED

Type

aRGB LED

Connector3 Pin(5V-ARGB)

Rated Voltage

5V DC

Power Consumption2.72 W
