hipset : AMD B650

CPU Support

Supports AMD Ryzen™ 7000 Series Desktop Processors

Socket AM5

Memory

4x DDR5, Maximum Memory Capacity 128GB

Memory Support DDR5 6600+(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200(OC)/5000(OC)/4800(JEDEC) MHz

Onboard Graphics

1x HDMI™

1x DisplayPort

Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz*

Support DP 1.4, maximum resolution of 8K 60Hz*

*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.

Expansions Slot :

2x PCI-E x16 slot

Support x16/ x4

1x PCI-E x1 slot

PCI_E1 PCIe 4.0 supports up to x16 (From CPU)

PCI_E2 PCIe 4.0 supports up to x4 (From Chipset)

PCI_E3 PCIe 3.0 supports up to x1 (From Chipset)

Storage

3x M.2 slot M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices

M.2_2 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices

M.2_3 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices

6x SATA 6G port

OS : Support for Windows® 11 64-bit, Windows® 10 64-bit

Dimensions : ATX (243.84mm x 304.8mm)
