Chipset AMD B650

CPU SUPPORT Supports AMD Ryzen™ 7000 Series Desktop Processors

Socket AM5

Memory 4x DDR5, Maximum Memory Capacity 128GB

Memory Support DDR5 6400+(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200(OC)/5000(OC)/4800(JEDEC) MHz

Onboard Graphics

1x HDMI™

1x DisplayPort

Support HDMI TM 2.1 with HDR, maximum resolution of 4K 60Hz*

Support DP 1.4, maximum resolution of 8K 60Hz*

EXPANSION SLOT

2x PCI-E x16 slot

Support x16/ x4

1x PCI-E x1 slot

Storage 2x M.2 slot

M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 2280 devices

M.2_2 (From CPU) supports up to PCIe 4.0 x4 , supports 2280 devices

6x SATA 6G port

RAID Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices*

Supports RAID 0 and RAID 1 for M.2 NVMe storage devices

* SATA_A1_A2 do not support RAID function.

USB 4x USB 2.0 (Front)

4x USB 3.2 Gen1 Type A (Rear)

2x USB 3.2 Gen1 Type A (Front)

3x USB 3.2 Gen2 Type A (Rear)

1x USB 3.2 Gen2 Type C (Front)

1x USB 3.2 Gen2x2 Type C (Rear)

LAN Realtek® RTL8125B 2.5Gbps LAN

WIRELESS / BLUETOOTH AMD Wi-Fi 6E

The Wireless module is pre-installed in the M.2 (Key-E) slot

Supports

MU-MIMO TX/RX

20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands

802.11 a/ b/ g/ n/ ac/ ax

Supports Bluetooth® 5.2**

* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 10 build 21H1 and Windows 11.

** Bluetooth 5.2 will be ready in Windows 10 build 21H1 and Windows 11.

Audio Realtek® ALC4080 Codec

7.1-Channel High Performance Audio

Supports S/PDIF output

Supports up to 32-Bit/384 kHz playback on front panel

OS : Support for Windows® 11 64-bit, Windows® 10 64-bit

Dimensions : m-ATX (243.84mmx243.84mm)
