Supports 12th Gen Intel® Core™ Processors (LGA1700)

13 Phase SPS Dr.MOS Power Design

Supports DDR4 5000MHz (OC)

1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 1 PCIe 3.0 x16, 1 PCIe 3.0 x1

Graphics Output Options: HDMI, DisplayPort

Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio

8 SATA3

2 Hyper M.2 (PCIe Gen4 x4)

1 Ultra M.2 (PCIe Gen3 x4 & SATA3)

1 USB 3.2 Gen2x2 Front Type-C

2 USB 3.2 Gen2 (Rear Type A+C)

8 USB 3.2 Gen1 (4 Rear, 4 Front)

Dragon 2.5G LAN, Intel® Gigabit LAN

ASRock Graphics Card Holder

CPU

- Supports 12th Gen Intel® Core™ Processors (LGA1700)

- Digi Power design

- 13 Power Phase design

- Supports Intel® Hybrid Technology

- Supports Intel® Turbo Boost Max 3.0 Technology

Chipset

- Intel® Z690

Memory

- Dual Channel DDR4 Memory Technology

- 4 x DDR4 DIMM Slots

- Supports DDR4 non-ECC, un-buffered memory up to 5000+(OC)*

- Supports ECC UDIMM memory modules (operate in non-ECC mode)

- Max. capacity of system memory: 128GB**

- Supports Intel® Extreme Memory Profile (XMP) 2.0

- 15μ Gold Contact in DIMM Slots

*Supports DDR4 3200 natively.

BIOS

- 256Mb AMI UEFI Legal BIOS with multilingual GUI support

- ACPI 6.0 Compliant wake up events

- SMBIOS 2.7 Support

- CPU Core/Cache, CPU GT, DRAM, VCCIN AUX, +1.05V PROC, +1.8V PROC, +0.82V PCH, +1.05V PCH Voltage Multi-adjustment

Graphics

- Intel® Xe Graphics Architecture (Gen 12)

- Dual graphics output: support HDMI and DisplayPort 1.4 ports by independent display controllers

- Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) @ 60Hz

- Supports DisplayPort 1.4 with DSC (compressed) max. resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @ 120Hz

- Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and DisplayPort 1.4 Ports
