-Chipset

Intel B365

-CPU SUPPORT

Socket 1151 for 9th and 8th Gen Intel Core, Pentium and Celeron processors

Maximum CPU TDP (Thermal Design Power): 95 Watt

*9th & 8th Generation Intel CoreTM Processor Family only support 300-Series.

-MEMORY

Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2666 MHz

2 x DDR4 DIMM Memory Slots

Max. Supports up to 32GB Memory

Each DIMM supports non-ECC 4/8/16GB DDR4 module

-INTEGRATED VIDEO

By CPU model

Supports DX12

Supports HDCP

-STORAGE

4 x SATA3 Connectors (6Gb/s)

1 x M.2 Key M 32Gb/s Connector: Supports PCI-E & SATA SSD, Intel Optane Technology

-LAN

Realtek RTL8111H - 10/100/1000Mb/s Controller

-CODEC

Realtek ALC887 8-Channel HD Audio

Supports HD Audio

-USB

6 x USB 3.1 Gen1 Ports (4 on rear I/Os and 2 via internal headers)

6 x USB 2.0 Ports (2 on rear I/Os and 4 via internal headers)

-EXPANSION SLOT

1 x PCI-E 3.0 x16 Slot

2 x PCI-E 3.0 x1 Slots

-REAR I/O

1 x PS/2 Mouse

1 x PS/2 Keyboard

4 x USB 3.1 Gen1 Ports

2 x USB 2.0 Ports

1 x HDMI Connector

1 x VGA Port

1 x LAN port

3 x Audio Jacks

-INTERNAL I/O

1 x USB 3.1 Gen1 Header (each header supports 2 USB 3.1 Gen1 ports)

2 x USB 2.0 Headers (each header supports 2 USB 2.0 ports)

4 x SATA3 6Gb/s Connectors

1 x Front Audio Header

1 x Front Panel Header

1 x CPU Fan Connector

1 x System Fan Connector

1 x 4-Pin Power Connector

1 x 24-Pin Power Connector

1 x Clear CMOS Header

1 x COM Port Header

-DIMENSION

Micro ATX Form Factor Dimension: 22.8cm x 17.7 cm ( W x L )

-ACCESSORIES

2 x SATA Cables

1 x I/O Shield

1 x DVD Driver

1 x Quick Guide

-OS SUPPORT

Supports Windows 10(64bit)
