Supports AMD Ryzen™ 7000 Series Processors

14+2+1 Phase Power Design, SPS

4 x DDR5 DIMMs, supports up to 6400+(OC)

3 PCIe 4.0 x16, 1 M.2 Key-E for WiFi

Graphics Output Options: 1 HDMI, 1 DisplayPort

7.1 CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio

1 Blazing M.2 (PCIe Gen5x4),

2 Hyper M.2 (PCIe Gen4x4),

2 SATA3

1 USB 3.2 Gen2x2 Type-C (Front),

1 USB 3.2 Gen2 Type-C (Rear),

1 USB 3.2 Gen2 Type-A (Rear),

8 USB 3.2 Gen1 (4 Rear, 4 Front),

12 USB 2.0 (8 Rear, 4 Front)

Realtek 2.5G LAN

CPU : Supports AMD Socket AM5 Ryzen™ 7000 Series Processors

Chipset : AMD B650

Memory

Dual Channel DDR5 Memory Technology

4 x DDR5 DIMM Slots

Supports DDR5 non-ECC, un-buffered memory up to 6400+(OC)*

Max. capacity of system memory: 128GB

Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules

BIOS : 256Mb AMI UEFI Legal BIOS with GUI support

Rear Panel I/O

2 x Antenna Mounting Points

1 x HDMI Port

1 x DisplayPort 1.4

1 x Optical SPDIF Out Port

1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (ReDriver)

1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver)

4 x USB 3.2 Gen1 Ports (USB32_12 are Lightning Gaming Ports. USB32_34 support Ultra USB Power.)

8 x USB 2.0 Ports

1 x RJ-45 LAN Port

1 x BIOS Flashback Button

1 x Line Out Jack (Gold Audio Jack)

1 x Microphone Input Jack (Gold Audio Jack)

Form Factor

ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm

8 Layer PCB

Accessories

1 x User Manual

2 x SATA Data Cables

4 x Screws for M.2 Sockets

1 x Standoff for M.2 Socket
