CPU

AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors

Chipset

AMD X670

Memory

2 x DIMM, Max. 64GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800MHz ECC and Non-ECC, Un-buffered Memory*

Dual Channel Memory Architecture

Supports AMD EXTended Profiles for Overclocking (EXPO™)

OptiMem II

Storage

Total supports 2 x M.2 slots and 2 x SATA 6Gb/s ports

AMD Ryzen™ 7000 Series Desktop Processors

M.2_1 slot (Key M), type 2280(supports PCIe 5.0 x4 mode)

AMD X670 Chipset

M.2_2 slot (Key M), type 2242/2260/2280

(supports PCIe 4.0 x4 mode)

2 x SATA 6Gb/s ports

Special Features

Extreme Engine Digi+

-5K Black Metallic Capacitors

ASUS Q-Design

- M.2 Q-Latch

- Q-DIMM

- Q-Slot

ASUS Thermal Solution

- M.2 heatsink

- Aluminum backplate

- M.2 Chipset Fan

- VRM heatsink design

ASUS EZ DIY

- BIOS FlashBack™ button

- BIOS FlashBack™ LED

- ProCool II

- Pre-mounted I/O shield

- SafeSlot

- SafeDIMM

AURA Sync

- AURA RGB header(s)

- Addressable Gen 2 header(s)

ROG STRIX HIVE

1 x USB Type-C® connects to Motherboard

1 x USB 3.2 Gen 2 port(s) (1 x USB Type-C®)

1 x USB 2.0 port(s) (1 x Type-A with BIOS

FlashBack™)

1 x Headphone jack with Mic in

1 x Mic in jack with Optical S/PDIF out

1 x EZ mode PBO button

1 x FlexKey button

1 x BIOS FlashBack™ button

1 x Volume Control Knob with Mute Button

Accessories

Cables

2 x SATA 6Gb/s cables

1 x ROG USB2.0 splitter cable

1 x Panel Cable

ROG FPS-II Card

1 x ROG FPS-II Card

ROG STRIX HIVE

1 x ROG STRIX HIVE

1 x USB Type-C® power connection cable

Additional Cooling Kit

1 x Thermal pad for M.2

Miscellaneous

1 x ASUS Wi-Fi moving antennas

1 x Cable ties pack

1 x Rubber Package(s) for M.2

1 x Q-Latch package(s) for M.2

1 x ROG key chain

1 x ROG Strix stickers

1 x ROG Strix thank you card

Installation Media

1 x User guide

Form Factor

Mini-ITX Form Factor

6.7 inch x 6.7 inch( 17cm x 17cm
